Heavy Copper PCB

Heavy copper printed circuit boards are in high demand and are widely used in various electronic industries. The PCBs have become one of the hottest PCBs with a good development prospect in the PCB industry.

Heavy copper PCB has another name, thick copper PCB, containing more than 3 ounces (oz) of copper on the inner or outer layers of printed circuit boards. With an appropriate substrate and thicker plating in the through-hole circuits, the copper weight makes these PCBs a reliable wiring platform. These boards are manufactured through a variety of etching and plating techniques. The goal is always to add copper thickness via plated holes and sidewalls.

MAX. copper thickness of Dihe Capability:12oz

Benefits of Heavy Copper PCB
Compared to conventional printed circuit boards, a PCB with heavy copper traces and/or planes offers several advantages.

I)A Simple & Strong Structure
When integrated into the PCB, high current circuits allow designers to achieve higher density and reduce the layer count. This also keeps the structure of the PCB relatively strong but uncomplicated.

II)Reduces Failure State
Complex printed circuit boards with high current requirements generate more heat. Copper has high heat-conducting abilities and helps to conduct heat away from vital temperature sensitive components.

III)Lower Production Costs
Although copper is expensive, rather than use copper cables, using PCBs with heavy copper results in an overall lowering of production costs.

APPLICATION OF Heavy Copper CIRCUIT BOARDS
Heavy Copper PCBs are generally used for high power distribution, heat dissipation, planar transformers, and power converters. Besides, the following are other applications that use heavy copper PCBs:
Power supplies for Radar Systems
power converters
Safety and Signal Systems
Welding equipment
Protection Relays
Power Line Monitors
Torque Controls
Overload Relays
Automotive industry
Solar panel manufacturers
Nuclear Power Applications
